Real-Time PCR TurboQ
TurboQ Real-Time PCR system is designed for multiplex and routine PCR applications with up to 4 targets. Inheriting the proven PCR instrument core competency from Blue-Ray Biotech, TurboQ brings versatile features to help lab researchers in performing diagnostic testing and researches.
Specification for Real-Time PCR TurboQ
SPECIFICATION
Sample Block
Fixed 96-well, compatible with regular profile 0.2 ml PCR tube, strip, and semi-skirted 96-well plate.
Sample Volume
10 - 100 µl
Peak Block Ramp Rate
2.5 °C/sec
Temperature Accuracy
± 0.25 °C (35 °C – 95 °C) of set point/ display temperature / Measured at 3 minutes after clock start
Temperature Uniformity Across Block
± 0.5 °C (30 seconds after clock start)
Gradient Temperature Range
60 - 99 °C
Gradient Temperature Difference
Max. span 25 °C
Heating Lid
105°C
Detection Channel
4 channels (Ch1: FAM, SYBR Green, Ch2: HEX, VIC, JOE, Ch3: ROX, Texas Red, Ch4:Cy5)
Storage Tempareture
-10 - 60 °C
PC Operation System
Windows 7 or higher
